The technology behind Kontur

Published: May 05, 2023

Pioneering Ground Penetrating Radar Technology

Our system is designed for high-resolution and three-dimensional subsurface mapping thanks to the use of our antenna arrays together with Examiner ™.
The system uses a patented and unique step-frequency radar technology, which is a vital part of evolving the rest of the GPR industry.

Man in a fieldMan in a field
Caption this
  • Bullet
  • List
  • Here

What is step-frequency?

Step-frequency is a radar waveform consisting of a series of sine waves with linearly increasing frequency.

The radar measures the phase and amplitude on each frequency and uses an inverse Fourier transform of this data to build a time-domain profile (A-scan). Thus, the step-frequency radar collects data in the frequency domain and converts the data to time-domain data through computer processing.

The step-frequency waveform gives the optimum source signature with a uniform frequency spectrum. The computer control allows the user to set the dwell time on each frequency as well as the start and stop frequencies.
